Qualifier is a leading 2D inspection system for sheetmetal parts which are usually made on CNC laser cutting machine, CNC turret punch press, etc. The workpiece image is captured by an industrial camera, then the actual contour and nominal contour are fitted together, the deviation map will show all the details including,
◆ The exact difference displayed by colour spikes between actual and nominal contour
◆ Every mistake such as wrong tooling installation, wrong NC program, etc
◆ The real-time measurement by function of Virtual caliper
◆ Output of the inspection report
Accuracy: ±0.05mm
Measurement Range:
1200 X 1800mm ( can be expanded by function of Merge Measurement )
